NRV10 User Guide
|
22
Analog Mixer Specifications
Mic Inputs 1-4 (analog - input to insert output)
Input Impedance 4kOhm
Maximum Input Level +14 dBu to -44 dBu, balanced
Channel-to-Channel Crosstalk < -100 dB
SNR -115 dB, A-weighted
Dynamic Range 115 dB, A-weighted
THD+N <0.001% (-100 dB) @ +4 dBu, 1 kHz
Frequency Response 20 Hz to 60 kHz, +/- 0.1 dB
Variable Gain 58 dB
Line Inputs (analog - input to insert output)
Input Impedance 20k Ohm, balanced
Maximum Input Level +20 dBu balanced
+17.8 dBV unbalanced
Channel-to-Channel Crosstalk < -80 dB
SNR -115 dB, A-weighted
Dynamic Range 115 dB, A-weighted
THD+N <0.002% (-94 dB) @ +4 dBu, 1 kHz
Frequency Response 20 Hz to 60 kHz, +/- 0.1 dB
Line Outputs (Analog)
Output Impedance 360 Ohm balanced
Maximum Output Level +20 dBu balanced
+17.8 dBV unbalanced
Frequency Response 20 Hz to 60 kHz, +/- 0.1 dB
Headphone Output (analog)
Maximum Output +7.2 dBu (5 Vpp) at THD < 0.01% into 32 ohms
Impedance 37 Ohms
Working Range 24 to 600 Ohms
Crosstalk < -80 dB
Inserts (Analog)
Output Impedance 180 Ohm, unbalanced
Input Impedance 10k Ohm, unbalanced
Maximum Send/Return Level +12 dBV, unbalanced
Aux Sends (Analog)
Output Impedance 150 Ohm
Nominal Send Level +12 dBV, unbalanced
Aux Returns (Analog)
Input Impedance 20k Ohm, balanced
Maximum Level +20 dBu, balanced
+17.8 dBV unbalanced
Headphone Output (analog)
Maximum Output +7.2 dBu at THD < 0.05% into 32 ohms
Working Range 24 to 600 Ohms
