11 Supplement
VEGAPULS 63 • Foundation Fieldbus
36514-EN-130228
Process conditions
The following specifications are for information. The specifications on the type plate must be noted.
Temperature
Antenna encapsulation Version Process temperature (measured on the process
fitting)
PTFE Standard -40 … +200 °C (-40 … +392 °F)
Low temperature -200 … +200 °C (-328 … +392 °F)
TFM-PTFE 8 mm Standard -40 … +150 °C (-40 … +302 °F)
Low temperature -196 … +200 °C (-321 … +392 °F)
PFA Standard -40 … +200 °C (-40 … +392 °F)
PFA 8 mm Standard -40 … +200 °C (-40 … +392 °F)
PTFE with additional pro-
cess seal
FKM -25 … +130 °C (-13 … +266 °F)
EPDM -40 … +130 °C (-40 … +266 °F)
Pressure
Version Process fitting Vessel pressure
Standard Flange PN 6 -1 … 6 bar (-100 … 600 kPa/-14.5 … 87 psig)
Flange PN 10 -1 … 10 bar (-100 … 1000 kPa/-14.5 … 145 psig)
Flange PN 16, PN 40 -1 … 16 bar (-100 … 1600 kPa/-14.5 … 232 psig)
Low temperature Flange DN 50, DN 80,
2", 3"
-1 … 20 bar (-100 … 2000 kPa/-14.5 … 290 psig)
Antenna encapsulation
PFA
Flange ≤ DN 65, 2½" -1 … 16 bar (-100 … 1600 kPa/-14.5 … 232 psig)
Flange ≥ DN 80, 3" -0.5 … 16 bar (-50 … 1600 kPa/-7.3 … 232 psig)
Aseptic SMS -1 … 6 bar (-100 … 600 kPa/-14.5 … 87 psig)
Tuchenhagen Varivent
Clamp 3", 3½", 4" -1 … 10 bar (-100 … 1000 kPa/-14.5 … 145 psig)
further hygienic fittings -1 … 16 bar (-100 … 1600 kPa/-14.5 … 232 psig)
Vibration resistance 4 g at 5 … 200 Hz according to EN 60068-2-6 (vibration
with resonance)
Shock resistance 100 g, 6 ms according to EN 60068-2-27 (mechanical
shock)
Electromechanical data - version IP 66/IP 67 and IP 66/IP 68; 0.2 bar
Options of the cable entry
Ʋ Cable gland M20 x 1.5 (cable: ø 5 … 9 mm)
Ʋ Cable entry ½ NPT
Ʋ Closing cap M20 x 1.5; ½ NPT
Ʋ Closing cap M20 x 1.5; ½ NPT
Plug options
Ʋ Signal circuit Plug M12 x 1, according to ISO 4400, Harting HAN,
7/8" FF
Ʋ Indication circuit M12 x 1 plug
