Fig. 8: Wiring plan B62-36G with protective function for sensor and signal
conditioning instrument
1 Sensor
2 Overvoltage arrester for sensor
3 Overvoltage arrester for signal input signal conditioning instrument/PLC
4 Signal conditioning instrument/PLC
5 Potential equalisation
Wiring plan
14 Overvoltage arrester • B62-36G
