9 Supplement

VEGASWING 51 • - transistor (PNP)

40552-EN-130322

Output variable
Output

Transistor output PNP

Load current

max. 250 mA (output, permanently short-circuit proof)

Voltage loss

< 3 V

Switching voltage

< 34 V DC

Blocking current

< 10 µA

Mode

Ʋ Min./Max.

Changeover by electronic connection

Ʋ Max.

Overflow protection

Ʋ Min.

Dry run protection

Voltage supply
Operating voltage

9.6 … 35 V DC

Power consumption

max. 0.5 W

Electromechanical data
Valve plug ISO 4400

Ʋ Wire cross-section

1.5 mm² (0.06 in²)

Ʋ Outer cable diameter

4.5 … 7 mm (0.18 … 0.28 in)

Valve plug ISO 4400 with IDC method of termination

Ʋ Wire cross-section

for wire cross-section of 0.5 … 1 mm² (0.02 … 0.04 in²)

Ʋ Single-wire diameter

> 0.1 mm (0.004 in)

Ʋ Wire diameter

1.6 … 2 mm² (0.06 … 0.08 in²)

Ʋ Outer cable diameter

5.5 … 8 mm (0.22 … 0.31 in)

Ʋ Connection frequency

10 x (on the same cross-section)

Electrical protective measures
Protection rating

Ʋ Valve plug ISO 4400

IP 65

Ʋ Valve plug ISO 4400 with IDC method

of termination

IP 67

Ʋ M12 x 1 plug connection

IP 66/IP 67 or IP 68 (0.2 bar)

Overvoltage category

III

Protection class

Approvals
Instruments with approvals can have different technical data depending on the version.
For that reason the associated approval documents of these instruments have to be carefully

noted. They are part of the delivery or can be downloaded under www.vega.com via "VEGA Tools"

and "serial number search" as well as via "Downloads" and "Approvals".
