6 Set up with the indicating and adjustment module
VEGAPULS 62 • HART and accumulator pack
40793-EN-121011
•
Process/measurement conditions:
– Measured value jumps, e.g. by truck loading
– Fast reaction time
– Large distance to the medium
Demonstration:
•
Adjustment for all applications which are not typically level meas-
urement
•
Sensor accepts all measured value changes within the measuring
range immediately
•
Typical applications:
– Instrument demonstration
– Object recognition/monitoring (additional settings required)
Through this selection, the sensor is adapted optimally to the applica-
tion or the location and measurement reliability under the various
basic conditions is increased considerably.
Enter the requested parameters via the appropriate keys, save your
settings with [OK] and jump to the next menu item with the [ESC] and
the [->] key.
Also the vessel form can influence the measurement apart from the
medium and the application. To adapt the sensor to these measure-
ment conditions, this menu item offers you different options for vessel
bottom and ceiling in case of certain applications.
Enter the requested parameters via the appropriate keys, save your
settings with [OK] and jump to the next menu item with the [ESC] and
the [->] key.
With this selection, the operating range of the sensor is adapted to
the vessel height and the reliability with different frame conditions is
increased considerably.
Independent from this, the min. adjustment must be carried out.
Enter the requested parameters via the appropriate keys, save your
settings with [OK] and jump to the next menu item with the [ESC] and
the [->] key.
Setup/Vessel form
Setup/Vessel height,
measuring range
