4 Test protocol - Recurring function test
If you copy this protocol, please note the date of the function test, the
measurement loop and the sensor serial number on each page.
Specifications VEGAPULS
Tester
Measurement loop name (sensor-TAG)
Sensor type
Serial number of the sensor
Software version
Required plant situation (according to chapter 2.4) □ maintained
Safety-instrumented system (SIS) □ yes
SIL activated □ yes
Medium or product group
Date of the setup (sensor documentation)
Date of the last function test (if carried out)
Test 3.1 - Restart of the sensor
Measured value before switching off Current value min. in mA Current value max. in mA
Measured value after switching on
again Current value min. in mA Current value max. in mA
Difference of the current values Current value min. in mA Current value max. in mA
Duration of the inspection in s
Test result
Min. and max. values □ Deviation ≤ 2 %
(test point successful) □ Deviation > 2 %
(test point not successful)
Test 3.2 - Verification of the current output
Lower simulation value (4 mA) Indication mA-meter in mA
Intermediate result ≤ 2 % (≤0.32 mA) □ Corresponds □ Does not correspond
Upper simulation value (20 mA) Indication mA-meter in mA
Intermediate result ≤ 2 % (≤0.32 mA) □ Corresponds □ Does not correspond
Test result - Total □ Corresponds □ Does not correspond
Recurring function test • for VEGAPULS series 60 15
4 Test protocol - Recurring function test
