VEGAPULS WL 61 • Foundation Fieldbus
38063-EN-121011
FF desciptor
Description
Unit
ECHO_CURVE_PLICSCOM_
LIMITS
Parameters as start and end
APPROVAL_WHG
Sensor acc. to WHG
DEVICE_STATE_CONFIG
Function check, maintenance required, out of specification
ELECTRONIC_TEMPERA-
TURE
Electronics temperature
RESET_PEAK_ELECTRON-
IC_TEMP
FOCUS_RANGE_CONFIG
Width focusing range, time for opening the focusing range, min.
measurement reliability in and outside the focusing range
NOISE_DETECTION_INFO
Increase of the system noise
NOISE_DETECTION_CON-
FIG
System noise treatment
ECHO_MEM_SAVE_CURVE_
TYPE
ECHO_MEM_STATE
Busy, curve type, error code
9.4 Dimensions
The following dimensional drawings represent only an extract of the possible versions. Detailed
dimensional drawings can be downloaded at www.vega.com/downloads under "Drawings".
