Connection tube Measuring cell seal Product temperature
316L FFKM -20 … +80 °C (-4 … +176 °F)
Transmitter protection Measuring cell seal Product temperature
PVDF FFKM -10 … +60 °C (+14 … +140 °F)
PE FKM (V iton) -20 … +60 °C (-4 … +140 °F)
PE FFKM -10 … +60 °C (+14 … +140 °F)
V
ibration resistance mechanical vibrations with 4 g and
5 … 100 H
z 9)
Electromechanical data
S uspension cable
-
C
onfiguration six wires, one suspension cable, one breather
capillary, screen braiding, foil, mantle
-
W
ire cross-section 0.5 mm²
-
W
ire resistance ≤ 0.036 Ω/ m
-
T
ensile strength ≥ 1200 N (270 pound force)
-
M
ax. length 1000 m (3280 ft)
-
M in. bending radius 25 mm (with 25 °C/77 °F)
-
D iameter approx. 8 mm (0.315 in)
-
colour (non-Ex/Ex) - PE black/blue
-
colour (non-Ex/Ex) - PUR, FEP blue/blue
C
able entry housing 1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5
S
crew terminals for cable cross-section
up to
1.5 mm² (AWG 16)
Voltage supply
S
upply voltage 9.6 … 36 V DC
P ermissible residual ripple
-
< 100 H z
U
ss
< 1 V
-
100 H z … 10 kHz
U
ss
< 10 mV
L oad see diagram
9) T ested according to the regulations of German Lloyd, GL directive 2.
