10 Supplement
VEGABAR 67 • Profibus PA - climate compensated
39445-EN-130321
Ʋ in the range of -50 … 0 °C
(-58 … +32 °F) and +100 … +150 °C
(+212 … +302 °F)
typ. ±4 K
Input variable
Adjustment
Adjustment range of the min./max. adjustment relating to the nominal measuring range:
Ʋ Percentage value -10 … 110 %
Ʋ Pressure value -20 … 120 %
Adjustment range of the zero/span adjustment relating to the nominal measuring range:
Ʋ zero -20 … +95 %
Ʋ span -120 … +120 % 10)
Ʋ Difference between zero and span max. 120 % of the nominal range
Recommended max. turn down 10 : 1
Nominal measuring ranges and overload capability in bar/kPa
The specifications are only an overview and refer to the measuring cell. Limitations due to the ma-
terial and version of the process fitting are possible. The specifications on the nameplate apply.
Nominal range Overload capacity, max.
pressure
Overload capacity, min. pres-
sure
Gauge pressure
0 … +0.2 bar/0 … +20 kPa
+20 bar/+2000 kPa -15 psig
0 … +0.4 bar/0 … +40 kPa +30 bar/+3000 kPa -15 psig
0 … +1 bar/0 … +100 kPa +35 bar/+3500 kPa -1 bar/-100 kPa
0 … +2.5 bar/0 … +250 kPa +50 bar/+5000 kPa -1 bar/-100 kPa
0 … +5 bar/0 … +500 kPa +65 bar/+6500 kPa -1 bar/-100 kPa
0 … +10 bar/0 … +1000 kPa +90 bar/+9000 kPa -1 bar/-100 kPa
0 … +25 bar/0 … +2500 kPa 130 bar/13 MPa -1 bar/-100 kPa
Nominal measuring ranges and overload capability in psig
The specifications are only an overview and refer to the measuring cell. Limitations due to the ma-
terial and version of the process fitting are possible. The specifications on the nameplate apply.
Nominal range Overload capacity, max.
pressure
Overload capacity, min. pres-
sure
Gauge pressure
0 … +3 psig
+290 psig -15 psig
0 … +6 psig +430 psig -15 psig
0 … +15 psig +500 psig -15 psig
0 … +35 psig +700 psig -15 psig
0 … +70 psig +950 psig -15 psig
0 … +150 psig +1300 psig -15 psig
0 … +350 psig +1900 psig -15 psig
10) Values less than -1 bar cannot be set.
