Flanges Process pressure Seal Wall thickness
Flange 2" 1500 lb RF, ANSI B16.5 95 bar (1378 psig) RTJ seal ring 3.91 mm (0.154 in)
Flange 2" 1500 lb RJF, ANSI B16.5 95 bar (1378 psig) RTJ seal ring 3.91 mm (0.154 in)
Process fitting - Rinsing air connection (D)
Thread G½
½ NPT
Process fitting - Ventilation fitting (E) (optional)
Flange DN 15 PN 40
Flange ½" 1500 lb RF, ANSI B16.5
Bypass 72 • with VEGAFLEX level sensor 7
