Electromechanical data - version IP 66/IP 67
C able entry
-
D ouble chamber housing
l
1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5; plug M12 x 1 for
VEGADIS 61 ( optional)
or:
l
1 x closing cap ½ NPT, 1 x blind stopper
½ NPT , plug M12 x 1 for VEGADIS 61
( optional)
or:
l
1 x plug (depending on the version), 1 x blind
stopper M20 x 1.5; plug M12 x 1 for VEGADIS
61 (
optional)
S pring-loaded terminals for wire cross-sec-
tion
< 2.5 mm² (AWG 14)
Indicating and adjustment module
V oltage supply and data transmission through the sensor
I ndication LC display in dot matrix
A djustment elements 4 keys
P rotection rating
-
unassembled IP 20
-
mounted into the sensor without cover
IP 40
M
aterials
-
H ousing ABS
-
I nspection window P olyester foil
Voltage supply
O perating voltage
-
N on-Ex and Ex-d instrument 20 … 72 V DC, 20 … 253 V AC, 50/60 H z
M ax. power consumption 4 VA; 2.1 W
Electrical protective measures
P
rotection rating
IP 66/IP 67
O vervoltage category III
P rotection class I
Approvals
I nstruments with approvals can have different technical data depending on the version.
T hat's why the associated approval documents have to be noted with these instruments. They are
part of the delivery or can be downloaded under www.vega.com via "VEGA Tools" and "serial
number search" as well as via "Downloads" and "Approvals".
