10 Supplement
10.1 Technical data
General data
316L corresponds to 1.4404 or 1.4435
M aterials, wetted parts
-
A ntenna E namel
-
A ntenna cone PTFE (TFM 1600)
-
seal, antenna system G raphite, PTFE-coated
M aterials, non-wetted parts
-
H ousing P lastic PBT (polyester), Alu die-casting powder-
coated, 316L
-
S eal between housing and housing
cover
NBR ( stainless steel housing), silicone (Alu/plastic
housing)
-
I nspection window in housing cover for
PLICSCOM
P olycarbonate (UL-746-C listed)
-
G
round terminal 316T i/316L
W
eight, depending on flange size and
housing material
27 … 41 kg (59.52 … 90.39 lbs)
Output variable
O
utput signal 4 … 20 mA/HART
HART output values
-
HART value (Primary Value) D istance to the level
-
HART value (Secondary Value) D istance to the level - scaled
S ignal resolution 1.6 µA
F ailure signal current output (adjustable) mA-value unchanged 20.5 mA, 22 mA, < 3.6 mA
(
adjustable)
M ax. output current 22 mA
L oad see load diagram under Power supply
D amping (63 % of the input variable) 0 … 999 s, adjustable
F ulfilled NAMUR recommendations NE 43
Input variable
M easured value distance between process fitting and product sur-
face
M in. distance from antenna end 100 mm (4 in)
M easuring range up to 35 m (114.83 ft)
