Operation
Plug connections Specification see "Connecting to power supply"
Signal lamp (LED)
-
Green Output closed
-
Red Output open
-
Red (flashing) Failure, output open
Output variable
Output Transistor output PNP
Load current max. 250 mA (output, permanently short-circuit
proof)
Voltage loss < 3 V
Turn-on voltage < 34 V DC
Blocking current < 10 µA
Mode
-
Min./Max. Changeover by electronic connection
-
Max. Overflow protection
-
Min. Dry run protection
Voltage supply
Operating voltage 9.6 … 35 V DC
Power consumption max. 0.5 W
Electromechanical data
Valve plug ISO 4400
-
Wire cross-section 1.5 mm² (0.06 in²)
-
Cable outer diameter 4.5 … 7 mm (0.18 … 0.28 in)
Valve plug ISO 4400 with IDC method of termination
-
Wire cross-section for wire cross-section of 0.5 … 1 mm²
(0.02 … 0.04 in²)
-
Single wire diameter > 0.1 mm (0.004 in)
-
Wire diameter 1.6 … 2 mm² (0.06 … 0.08 in²)
-
Cable outer diameter 5.5 … 8 mm (0.22 … 0.31 in)
-
Connection frequency 10 x (on the same cross-section)
Electrical protective measures
Protection rating
-
Valve plug ISO 4400 IP 65
-
Valve plug ISO 4400 with IDC method of
termination IP 67
-
M 12 x 1 plug connection IP 66/IP 67 or IP 68 (0.2 bar)
