9 Supplement
VEGACAP 66 • - two-wire
30023-EN-130916
Ʋ Single chamber housing – 1 x IP 68 cable gland M20 x 1.5; 1 x blind plug
M20 x 1.5
or:
– 1 x closing cap ½ NPT, 1 x blind plug ½ NPT
Connection cable
Ʋ Wire cross-section > 0.5 mm² (AWG 20)
Ʋ Wire resistance < 0.036 Ω/m (0.011 Ω/ft)
Ʋ Tensile strength < 1200 N (270 lbf)
Ʋ Standard length 5 m (16.4 ft)
Ʋ Max. length 1000 m (3280 ft)
Ʋ Min. bending radius 25 mm (0.984 in) with 25 °C (77 °F)
Ʋ Diameter approx. 8 mm (0.315 in)
Ʋ Colour - standard PE Black
Ʋ Colour - standard PUR Blue
Ʋ Colour - Ex-version Blue
Adjustment elements
DIL switch for measuring range selection
Ʋ range 1 0 … 20 pF
Ʋ range 2 0 … 85 pF
Ʋ range 3 0 … 450 pF
Voltage supply
Operating voltage
10 … 36 V DC (via the signal conditioning instrument)
Electrical protective measures
Protection rating
Ʋ Plastic housing IP 66/IP 67
Ʋ Aluminium and stainless steel stand-
ard
IP 66/IP 68 (0.2 bar) 2)
Ʋ Aluminium and stainless housing
(optionally available)
IP 66/IP 68 (1 bar)
Overvoltage category III
Protection class II
Functional safety (SIL)
Functional safety is already activated on instruments with SIL qualification ex factory. On instru-
ments without SIL qualification ex factory, the functional safety must be activated by the user via
the display and adjustment module or via PACTware for applications according to SIL.
Functional safety according to IEC 61508-4
Ʋ Single channel architecture (1oo1D) up to SIL2
2) A suitable cable is the prerequisite for maintaining the protection rating.
