9 Supplement
9.1 Technical data
General data
Material 316L corresponds to 1.4404 or 1.4435
Materials, wetted parts
- Process fitting - Thread
316L
- Process fitting - Flange 316L
- Process seal Klingersil C-4400
- Tuning fork 316L
- Extension tube ø 43 mm (1.7 in) 316L
Materials, non-wetted parts
- Housing
Plastic PBT (Polyester), Alu die-casting pow-
der-coated, 316L
- Seal ring between housing and
housing cover
NBR (stainless steel housing), silicone (Alu/
plastic housing)
- Ground terminal 316L
Weights
- with plastic housing
1500 g (53 oz)
- with Aluminium housing 1950 g (69 oz)
- with stainless steel housing 2300 g (81 oz)
- Extension tube approx. 2000 g/m (21.5 oz/ft)
Sensor length 0.3 … 6 m (1 … 20 ft)
Output variable
Output
floating transistor output, overload and perma-
nently shortcircuit proof
Load current max. 400 mA
Turn-on voltage max. 55 V DC
Blocking current <100 µA
Modes (adjustable) min./max.
Integration time
- when immersed
approx. 0.5 s
- when laid bare approx. 1 s
Ambient conditions
Ambient temperature on the housing
-40 … +80 °C (-40 … +176 °F)
Supplement
VEGAVIB 67 - with transistor output 29
