VEGABAR 15 3
Product description
1 Product description
1.1 Function and configuration
VEGABAR 15 is a process pressure trans-
mitter with a piezoresistive sensor element for
pressure measurement of gas, steam or
liquids between 1 bar and 600 bar (relative
pressure). For use in dense, non-uniform and
cristallizing products, a version with flush
diaphragm is available. A standardised
4 … 20 mA current signal is available as
output signal.
1.2 Measuring ranges
Nominal meas. range Max. test pressure
Gauge pressure ranges
0 ... 1.0 bar/ 0 ... 100 kPa 2 bar / 200 kPa
0…1.6 bar / 0…160 kPa 8 bar / 800 kPa
0…2.5 bar / 0…250 kPa 8 bar / 800 kPa
0…4.0 bar / 0…400 kPa 8 bar / 800 kPa w ith flush version
0…6.0 bar / 0…600 kPa 20 bar / 2 000 kPa w ith flush version
0…10.0 bar / 0…1 000 kPa 20 bar / 2 000 kPa w ith flush version
0…16.0 bar / 0…1 600 kPa 50 bar / 5 000 kPa w ith flush version
0…25.0 bar / 0…2 500 kPa 50 bar / 5 000 kPa w ith flush version
0…40.0 bar / 0…4 000 kPa 80 bar / 8 000 kPa w ith flush version
0…60.0 bar / 0…6 000 kPa 200 bar / 20 000 kPa w ith flush version
0…100 bar / 0…10 000 kPa 200 bar / 20 000 kPa
0…160 bar / 0…16 000 kPa 320 bar / 32 000 kPa
0…250 bar / 0…25 000 kPa 600 bar / 60 000 kPa
0…400 bar / 0…40 000 kPa 600 bar / 60 000 kPa
0…600 bar / 0…60 000 kPa 900 bar / 90 000 kPa
