3 VEGAMET 407 AF/AFT
Technical data
Power supply Value Tolerance Frequency
standard AC 220 V +15 % -10 % 50 / 60 Hz
AC 230 V +10 % -15 %
options AC 110 V 50 / 60 Hz
130 V +15 %
240 V -10 %
260 V
AC 24 V +15 % 50 / 60 Hz
42 V -10 %
48 V
DC 9 … 16 V
16 … 60 V
Power consumption at U
N
: approx. 7 VA
Voltage for the transducer on
terminals 1 and 2 (terminal 3 and 4 bridged)
approx. 22 V
Resistance per conductor to the transducer max. 50 Ohm
Voltage for the transducer on
terminals 1 and 2 (terminal 3 and 4 open)
(only for electrodes with oscillator type 117)
approx. 15 V
Resistance per conductor to the transducer max. 50 Ohm
Indication analog indication 0 … 100 %
Output 1 type current output
range 0 … 20 mA or 4 … 20 mA
load max. 750 Ohm
floating VEGAMET 407 AFT
Output 2 type current output
range 0 … 5 V, max. 2 mA
for connection of
max. 10 auxiliary limit switches VEGASEL
Output 3 type voltage output
range 0 … 10 V, max. 2 mA
Output 4 type relay output
function fail safe
contact 1 spdt
relay data:
contact material
AgCdO and Au plated
min. turn-on voltage 10 mV
switching current 10
µ
A
max. turn-on voltage AC 250 V, DC 60 V
switching current AC 2 A, DC 1 A
breaking capacity 125 VA, 60 W
Integration time 0 … 20 sec.
Permissible ambient temperature on the housing -20
°
C … +50
°
C / -4 … 122
°
F
Storage and transport temperature -20
°
C … +70
°
C / -4 … 158
°
F
Housing type plastic ABS light grey
protection IP 40
dimensions B = 53 mm, T = 143 mm, H = 127 mm
Terminal board: for cross section area of conductors max. 1 x 1,5 mm 2
Weight: with plug-in socket approx. 710 g
