VEGA Capacitive electrodes EL 4 … 20 mA - Compact - Manual (Page 14)

14 Capacitive electrodes EL 4 … 20 mA - Compact
22652-EN-020809
158
25
L (min. 100/max. 4000 mm)
Ø 14
48
85 32,5
M20x1,5
Product description
1.5 Dimensions
Dimensions of capacitive electrode type EL … Ex 0
Type EL 11 (partly insu-
lated)
(Ex 0)
110
85 32,5
M20x1,5
Ø 20
L1
Ø 15
35
L (min. 100/max. 4000 mm)
20
SW 60
G 1½ A
L (min. 100 mm, max. 4000 mm)
Type EL 21 (fully insulated)
(Ex 0)
A
35
L (min. 100/max. 4000 mm)
20
G 1½ A
SW 60
110
85 32,5
M20x1,5
L (min. 100 mm, max. 4000 mm)
Insulation length L1:
PP: 100 mm
PTFE: 50 mm
StEx: max. 100 mm
Type EL 24 (fully insulated,
for adhesive products)
(Ex 0)
Ш 12
Ш 14
110
35
L (min. 120/max. 4000 mm)
20
SW 60
G 1½ A
85 32,5
M20x1,5
L (min. 120 mm, max. 4000 mm)
Type EL 29 (fully
insulated)
L (min. 120, max. 3000 mm)
Type EL 31 (partly insu-
lated)
(Ex 0)
L (min. 400 mm, max. 25000 mm)
Insulation length L1:
PP: 100 mm
PTFE: 50 mm
StEx: max. 100 mm
110
85 32,5
M20x1,5
35
L (min. 400/max. 25.000 mm)
20
SW 60
G 1½ A
Ø 20 L1
Ш 40
Ш 8
200
16
70
100
Insulation A
outer-ø
PE 2.0 mm 20 mm
PTFE 2.0 mm 20 mm
PTFE 3.2 mm 16 mm
PFA 2.0 mm 20 mm
35
L (min. 400/max. 25.000 mm)
20
SW 60
G 1½ A
Ш 40
Ш 3
200
Ш 5
Ш 3
120
Ш 40
Ш 20
Ш 36
110
85 32,5
M20x1,5
Type EL 42 (fully insulated)
(Ex 0)
L (min. 400 mm, max. 25000 mm)
