F ulfilled NAMUR recommendations NE 43
Input variable
M easured value distance between process fitting and product sur-
face
M in. distance from antenna end 50 mm (1.969 in)
R ecommended meas. range depending on the antenna diameter
-
ø 40 mm (1.575 in) up to 10 m (32.81 ft)
-
ø 48 mm (1.89 in) up to 15 m (49.21 ft)
-
ø 75 mm (2.953 in), ø 95 mm (3.74 in),
parabolic antenna
up to 30 m (98.43 ft)
M ax. measuring range up to 35 m (114.83 ft)
Reference conditions to measuring accuracy (similar to DIN EN 60770-1)
R eference conditions according to DIN EN 61298-1
-
T emperature
+ 18 … +30 °C (+64 … +86 °F)
-
R elative humidity 45 … 75 %
-
A ir pressure 860 … 1060 mbar/86 … 106 kPa (12.5 … 15.4 psig)
O ther reference conditions
-
R eflector ideal reflector, e.g. metal plate 2 x 2 m
-
F
alse reflections
B
iggest false echo, 20 dB smaller than the useful
echo
Characteristics and performance data
F requency K- band (26 GHz technology)
M
eas. interval approx. 1 s
B eam angle -3 dB with horn antenna, depending on antenna diameter
-
ø 40 mm (1.575 in) 22°
-
ø 48 mm (1.89 in) 18°
-
ø 75 mm (2.953 in) 10°
-
ø 95 mm (3.74 in) 8°
B
eam angle -3 dB with parabolic antenna 4°
S tep response or adjustment time 4) < 1 s (dependent on the parameter settings)
M ax. level change A djustable up to 1 m/min. (dependent on the
parameter adjustment)
M ax. emitted HF power of the antenna system
-
P ulse peak power < 2 mW
-
P ulse duration < 2 ns
4) T ime to output the correct level (with max. 10 % deviation) after a sudden
level change.
