9 Supplement
9.1 Technical data
General data
316L corresponds to 1.4404 or 1.4435, 316Ti corresponds to 1.4571
Materials
- Housing
plastic PBT
- Ground terminal 316Ti/316L
- Inspection window of the indication
Weight
approx. 0.5 kg (1.102 lbs)
Ambient conditions
Ambient temperature
- without display
-40 … +85 °C (-40 … +185 °F)
- with display -20 … +70 °C (-40 … +158 °F)
Storage and transport temperature -40 … +85 °C (-40 … +185 °F)
Electromechanical data
Cable gland
2 x cable entry M20 x 1.5 (cable-ø 5 … 9 mm)
Screw terminals for wire cross-section up to 2.5 mm² (AWG 14)
Indicating and adjustment elements
Adjustment elements
2 x 2 keys, 2 x 1 rotary switch
Adjustment elements with display 2 keys, 1 rotary switch
Display (optional) LC multiple function display with bar graph (20
segments, digital value 4-digit), tendency in-
dicator for rising or falling values
Adjustment circuit
Connection to
VEGAWELL 72 4 … 20 mA/HART, VEGABAR
74, VEGABAR 75
Connection cable to the sensor VEGA special cable with breather capillaries
Cable length max. 200 m
Voltage supply
Supply voltage
- without display
12 … 36 V DC
- with display 17 … 36 V DC
