Pressure transmitter D85 9
Product description
1.5 Technical data
Mechanical data
Materials, wetted parts
Process connection stainless steel 1.4571, 1.4435
Diaphragm Duratherm 600
Materials, non-wetted parts
Housing Alu (sea-water resistant) Pe-powder coated,
stainless steel 1.4571
Cooling body (option) Alu eloxated
Heat screen (option) Alu eloxated
External connection housing high resistance plastic PBT (Polyester)
Ground terminal stainless steel 1.4305
Window of the display module safety glass
Weights
Basic weight without housing approx. 1.6 kg
External housing approx. 400 g
Adjustment and display elements
Pressure transmitter
- terminal insert
without adjustment elements
- adjustment insert 2 keys, 1 rotary switch
Nominal meas. range (gauge pressure) G auge pr. resistance Low pr. resistance
0…0.1 bar / 0…10 kPa 2.5 bar / 250 kPa -0.1 bar / -10 kPa
0…0.2 bar / 0…20 kPa 5 bar / 500 kPa -0.2 bar / -20 kPa
0…0.4 bar / 0…40 kPa 10 bar / 1 000 kPa -0.4 bar / -40 kPa
0…1.0 bar / 0…100 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
0…2.5 bar / 0…250 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
0…5.0 bar / 0…500 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
0…10.0 bar / 0…1 000 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
0…20.0 bar / 0…2 000 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
-0.5…+0.5 bar / -50…+50 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
-1.0…0.0 bar / -100…0 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
-1.0…+1.5 bar / -100…+150 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
-1.0…+4.0 bar / -100…+400 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
-1.0…+10.0 bar / -100…+1 000 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
-1.0…+20.0 bar / -100…+2 000 kPa 25 bar / 2 500 kPa -1.0 bar / -100 kPa
