Wiha articulated hose system.
The universal pipe system.
maxiflex
®
programme ø
¼"
(6.35 mm).
maxiflex
®
programme ø
¼"
(6.35 mm).
Order-No. Article-No.
J
27084 412 2010 1
maxiflex
®
-set, assembled
1 threaded nipple R 1/4"
22 segments
1 cylindrical nozzle ø 3.2 mm
Total length: 320 mm
27108 412 2920 1
Separation wedge
27109 412 2930 1
Assembly pliers
27104 412 2810 1
Set with magnetic foot and ball valve,
assembled
1 threaded nipple R 1/4"
22 segments
1 cylindrical nozzle ø 3.2 mm
Magnetic foot with hose nozzle ø 11 mm
Extra: Magnetic adhesion 80 N
27105 412 2820 1
Set with magnetic foot, assembled
2 threaded nipples R 1/4"
44 segments, length: 2 x 320 mm
2 cylindrical nozzles ø 3.2 mm
Magnetic foot with hose nozzle ø 11 mm
Extra: Magnetic adhesion 80 N
27106 412 2830 1
Set with magnetic foot and ball valve,
assembled
1 threaded nipple R 3/8" for hose diameter 1/2"
1 reduction of hose diameter from 1/2" to 1/4"
22 segments
1 cylindrical nozzle ø 3.2 mm
Magnetic foot with hose nozzle ø 11 mm
Extra: Magnetic adhesion 150 N
27107 412 2850 1
Distribution block with 3 ball valves
Ball valves with threaded outlets R 1/4"
Hose nozzle ø 11 mm
Extra: Magnetic adhesion 4 x 95 N
30518 412 2000 1
maxiflex
®
basic set
3 tubes à 280 mm
2 cylindrical nozzles ø 1.6 mm
3 cylindrical nozzles ø 3.2 mm
2 cylindrical nozzles ø 5.6 mm
1 flat nozzle 24 mm
1 flat nozzle 24 mm, 7 holes ø 1.5 mm
2 Y-junctions
1 spherical double socket segment
2 threaded nipples R 1/8"
3 threaded nipples R 1/4"
1 adapter for LOC-LINE
®
1 assembly pliers
1 separation wedge
Order-No. Article-No.
J
27085 412 2030 1
Pack with 22 segments, assembled
Length: 280 mm
27086 412 2060 1
Pack with 80 segments, assembled
Length: 1000 mm
27087 412 2220 1
Pack with 4 cylindrical nozzles ø 1.6 mm
27088 412 2240 1
Pack with 4 cylindrical nozzles ø 3.2 mm
27089 412 2260 1
Pack with 4 cylindrical nozzles ø 5.6 mm
27090
412 2280 1
Pack with 2 flat nozzles
, 7 holes (
ø 1.5 mm)
24 mm wide
27091 412 2330 1
Pack with 2 flat nozzles
24 mm wide
27092 412 2420 1
Pack with 4 angular nozzles ø 1.6 mm
27093 412 2440 1
Pack with 4 angular nozzles ø 3.2 mm
27094 412 2460 1
Pack with 4 angular nozzles ø 5.6 mm
27095 412 2480 1
Pack with 2 multi-hole angular nozzles,
7 holes (ø 2 mm)
27096 412 2640 1
Pack with 4 adapters for LOC-LINE
®
Flexi
and ARIANA Cool-Line
27097 412 2650 1
Pack with 4 spherical double socket
segments
27098 412 2660 1
Pack with 4 double nipples
27099 412 2710 1
Pack with 4 threaded nipples R 1/8"
27100 412 2720 1
Pack with 4 threaded nipples R 1/4"
27101 412 2740 1
Pack with 2 Y-junctions
27102 412 2770 1
Pack with 2 regulating valves
27103 412 2780 1
Pack with 2 segment clips
28006 412 2020 1
6 short nozzles, assembled, with:
1 threaded nipple R 1/8"
1 segment
1 short cylindrical nozzle ø 2.5 mm
29446 412 2760 1
Ball valve with threaded outlet G 1/4"
®
