Connection diagram with RGB

LED dimmer

The dimmer controller can also be used to dim RGB LED
strips through a DC-controlled RGB LED dimmer. Here, 3
channels are being used.

4 ch. 0/1 to 10V dimmer
controller VMB4DC

DC controlled
RGB dimmer
