Vitek VT-3508 - Manual (Page 3)

CLOCK RADIO WITH ALARM AND PROJECTOR
MODEL: VT-3508
1. POWER SELECTOR (AUTO/ON/OFF)
2. LED INDICATOR
3. AUTO MODE INDICATOR
4. SNOOZE BUTTON
5. ALARM SET/OFF
6. TIME SET BUTTON
7. SLEEP BUTTON
8. LOW/HIGH DIMMER SWITCH
9. HOUR BUTTON
10.MIN BUTTON
11.VOLUME DIAL
12.BAND SELECTOR (AM/FM)
13.TUNING DIAL
14.BACKUP BATTERY COMPARTMENT
15.FM-ANTENNA
16.POWER CORD
17.RADIO FREQUENCY SCALE
18.PROJECTION ON/OFF BUTTON
19.PROJECTOR
20.PROJECTOR TIME SET BUTTON
21.HOUR BUTTON
22.MIN BUTTON
23.FOCUS DIAL
24.ALARM RADIO/BUZZ SELECTOR
AC POWER SUPPLY
Before connecting, make sure that the electrical
supply voltage is compatible with the device’s
voltage requirements.
CAUTION
• Remove the AC plug from the outlet if the device
will not be used for a long period of time.
• Do not attempt to repair this device yourself;
there are no user-serviceable parts inside.
• Do not allow water to splash or spill onto the
device in order to avoid fire and electric shock.
• Do not obstruct the natural ventilation of the
device; do not place it in closed bookshelves or
on shelves were there is not good ventilation.
• Do not place sources of open flames, like can-
dles, on the device.
• In case of malfunction, contact an authorized
service center.
CLOCK
• Open the battery compartment (14) and install
one 6F-22 type 9V battery (not included). The
battery is used to save information regarding the
current time and alarm settings in case of AC
power interruption.
• Set the AUTO/OFF/ON (1) selector to the Off
position and plug the power plug into the outlet;
the display will start to blink.
• To set the current time, press and hold the TIME
(6) button, then use the HOUR (10) and MIN (9)
buttons to set the current time.
THE CURRENT TIME ON THE CLOCK AND THE
PROJECTED TIME ARE SET SEPARATELY.
SETTING THE PROJECTED TIME
• To project the current time onto the wall, point
the projector away from itself and into a horizon-
tal position.
• Turn on the projector using the PROJECTION
ON/OFF (18) button; use the FOCUS (23) dial to
achieve a sharp image on the wall.
• To set the current time on the projector, press
and hold the TIME (20) button, then use the MIN
(22) and HOUR (21) buttons to set the current
time.
NOTE: THE PROJECTION DISTANCE OF THE
TIME IN A DARK ROOM IS FROM 0.9 TO 2. 7 m.
SETTING THE ALARM TIME
• Press and hold the ALARM (5) button; use the
HOUR (9) and MIN (10) buttons to set the
desired alarm time.
WAKING UP TO THE RADIO
• Set the alarm time as instructed above.
• Set the AUTO/OFF/ON (1) selector to the On
position.
• Tune the radio to the desired station and adjust
the volume.
• Set the ALARM RADIO/BUZZ (24) selector to
RADIO.
• Set the AUTO/ON/OFF (1) selector to AUTO.
The alarm will activate at the pre-set time and
will automatically turn off after 1 hour and 59
minutes.
WAKING UP TO BUZZER ALARM
• Set the alarm time as indicated above.
• Rotate the VOLUME/BUZZ (24) dial counter-
clockwise until it clicks in order to activate the
BUZZ alarm mode.
• Set the Auto/Off/On (1) selector to Auto. The
buzzer alarm will activate at the set alarm time.
TURNING OFF THE ALARM
• Press the ALARM SET/OFF (5) button to turn off
the alarm; the set alarm time remains saved for
use the next day.
• Set the AUTO/ON/OFF (1) selector to the OFF
position to turn off the alarm permanently.
SNOOZE MODE
• You can temporarily silence the alarm (buzzer or
radio) by pressing the Snooze (4) button; the
alarm will automatically activate again in 9 min-
utes.
