Trade Mark Versa-Lift 25_35 - Manual

264
(22')
58
FORWARD 11°,BACK 6°
35000 LBS @ 24" EXTENDED
25000 LBS @ 24" RETRACTED
COUNTERWEIGHT 6000 LBS
REAR 22X8 POLY
FRONT 28X16 POLY
(785) 594-7474 FAX (785) 594-7475 439 EAST HIGH STREET, BALDWIN CITY, KS 66006
8
95
OAL
92
LIFT
3
12
112
114
24
76
147
36
6°
96
11°
DRIVE SYSTEM:
TILT:
WEIGHTS:
GRADE:
TIRES:
ENGINE: GM 3.0L
HYDROSTATIC
TOTAL 34500 LBS
BOOM 3000 LBS
EMPTY 38%
LOADED 17%
FORKS 1500 LBS
27
20°
