Omnimount 30.0 CA-MP Sales Sheet User Manual
0 ca, Technical data sheet

30.0 CA
technical data sheet
05052010
800.MOUNT.IT (800.668.6848)
OmniMount, an innovator of A/V mounts and
furniture for more than a quarter century,
is the choice of professional installers and
the brand most recommended by flat panel
manufacturers. The Stainless Steel Series is
our patented top-of-the-line speaker mounting
solution which combines quality, durability
and ease-of-installation. The 30.0 CA is
the proven choice for mounting bookshelf
speakers up to 30 lbs (13.6 kg) on a ceiling.
Product Specifications
Fits most: Bookshelf speakers
Supports up to: 30 lbs (13.6 kg)
Base rotation: 360º
Pan: 180º
Tilt: 0º to +90º
Color: Black and White
Product Benefits
•
Polymer-injected ball controls resonance
frequencies for better sound
•
Ball and clamp design for greater mounting flexibility
•
Includes clamp and jaw
•
Designed to attach to the back of an enclosure,
then to ceiling or any other surface
•
Provides 360° of horizontal coverage and
up to 90° of vertical coverage
•
Stainless steel hardware for strength and durability
•
Suitable for all-weather use
•
Includes complete hardware kit
Dimensions WxDxH inches (mm)
Wt lbs (kg)
Product Box
TBD
TBD
Master Carton
TBD
TBD
Box Contents
Qty
Clamp assembly
1
Mounting plate
1
Ball shaft
1
Box Contents
Qty
Polymer ball
1
Complete installation hardware kit
1
Instruction manual
1
4.29 (109)
5.24 (133)
6.77
(172)
9.29
(236)
Color Stock Code
Packaging UPC
MC UPC
Americas
Black 768114IFK
728901007224 728901700712
International
Black
NA
NA
NA
Americas
White 768124IFK
728901007545 728901700798
International
White
NA
NA
NA
