30.0 ST-MP
technical data sheet
04192010
800.MOUNT.IT (800.668.6848)
OmniMount, an innovator of A/V mounts and furniture
for more than a quarter century, is the choice of
professional installers and the brand most recommended
by flat panel manufacturers. The Stainless Steel Series
is our patented top-of-the-line speaker mounting
solution which combines quality, durability and ease-
of-installation. The 30.0 ST-MP is the most versatile
and proven choice for mounting bookshelf speakers
up to 30 lbs (13.6 kg) on a ceiling, wall or floor
with a connection to anywhere on the speaker.
Product Specifications
Fits most: Bookshelf speakers
Supports up to: 30 lbs (13.6 kg)
Pan: 180º
Color: Black and White
Product Benefits
•
Polymer-injected ball controls resonance
frequencies for better sound
•
Ball and clamp design for greater mounting flexibility
•
Connects from ceiling/wall/floor to top/back/side/bottom
•
Includes clamp, jaw and mounting plate
•
Stainless steel hardware for strength and durability
•
Suitable for all-weather use
•
Includes complete hardware kit
Dimensions WxDxH inches (mm)
Wt lbs (kg)
Product Box
8.1 x 6.3 x 4.5 (205x160x115)
TBD
Master Carton
NA
NA
Box Contents
Qty
Mounting plate
1
Ball shaft
1
Polymer ball
1
Box Contents
Qty
Clamp assembly
1
Complete installation hardware kit
1
Instruction manual
1
Color Stock Code
Packaging UPC
MC UPC
Americas
Black 778114IFK 728901007552 728901700804
International
Black
NA
NA
NA
Americas
White 778124IFK 728901007569 728901700811
International
White
NA
NA
NA
TO
FLOOR/DECK
ETC.
TO
CEILING
TO
CEILING
TO WALL
ST-PA ST WITH OPTIONAL PIPE ADAPTER
4.61
(117)
5.75
(146)
4.61 (117)
0.51
(13)
4.49
(114)
3.5
(89)
2.6 (66)
3.31 (84)
1.61 (41)
4.29
(109)
2.09
(53)
