Omnimount 30.0 WA Sales Sheet - Manual

30.0 WA
technical data sheet
05052010
800.MOUNT.IT (800.668.6848)
OmniMount, an innovator of A/V mounts and
furniture for more than a quarter century, is the
choice of professional installers and the brand
most recommended by flat panel manufacturers.
The Stainless Steel Series is our patented top-
of-the-line speaker mounting solution which
combines quality, durability and ease-of-
installation. The 30.0 WA is the proven choice
for mounting bookshelf speakers up to 30 lbs
(13.6 kg) with a wall-to-back connection.
Product Specifications
Fits most: Bookshelf speakers
Supports up to: 30 lbs (13.6 kg)
Pan: 180º
Color: Black and White
Product Benefits
•
Polymer-injected ball controls resonance
frequencies for better sound
•
Ball and clamp design for greater mounting flexibility
•
Includes clamp and jaw
•
Connects from wall to back of the enclosure
•
Limited range of horizontal and vertical coverage
•
Stainless steel hardware for strength and durability
•
Suitable for all-weather use
•
Includes complete hardware kit
10
(254)
6.26
(159)
5.39 (137)
Dimensions WxDxH inches (mm) Wt lbs (kg)
Product Box TBD TBD
Master Carton TBD TBD
Box Contents Qty
Wall bracket 1
Ball shaft 1
Polymer ball 1
Plastic cover 1
Box Contents Qty
Clamp assembly 1
Complete installation hardware kit 1
Instruction manual 1
Color Stock Code Packaging UPC MC UPC
Americas Black 714114IFK 728901007859 728901701085
International Black NA NA NA
Americas White 714124IFK 728901007521 728901700774
International White NA NA NA
