inches (mm)

800.MOUNT.IT (800.668.6848)

PANEL ATTACHMENT -

VESA COMPATABILITY (mm)

WALL MOUNTING

-5˚ to +15˚

5.2

(131)

4.8

(121)

5

(126)

3

(76)

4.8

(121)

(100)

(100)

(75)

(75)

2.5

(63)

1.8

(47)

.9

(22)

R .25

(6)

.75

(19)

Ø (7)

06132011

QM100 T

line drawing
