Omnimount QM100-T Sales Sheet User Manual
Qm100 t, Series, Product information sheet

Series
800.MOUNT.IT (800.668.6848)
OmniMount, an innovator of A/V mounts and furniture for more
than a quarter century, is the choice of professional installers
and the brand most recommended by flat panel manufacturers.
The Classic Series is a full line of fixed, tilt, flip down and
full motion mounting solutions designed with simplicity and
reliability in mind. The QM100 T is a small tilt mount
that is the obvious choice for basic installations.
Product Specifications
Fits most: 13" - 26" flat panels
Supports up to: 40 lbs (18.1 kg)
Tilt: -5º to +15º
Mounting profile: 1.8" (46mm)
VESA compliant: 75x75 & 100x100
Mounting: Single-stud or solid wall
UL listed: Yes
Warranty: 5 years
Color: Platinum
Product Benefits
•
Low 1.8" (46mm) mounting profile
•
Tilt -5° to +15° to reduce glare
•
Adjust tilt without removing flat panel
•
Simple to install and use
•
Includes complete hardware kit
06132011
QM100 T
product information sheet
The QM100 T can be installed
inverted to achieve a -15º tilt
UCL
FP-CL
75/100 CL
75/100 FD
U2 Fixed
**
QM100 T
*
*
also available in small and medium fixed
**
also available in large/extra large
***
also available in small and medium
U3 Tilt
***
2004 CEDIA Manufacturers’
Excellence Award
