For Application Using OmniMounts FP-CL
NOTE:
Two 1/4”-20 nuts (P-B) must be used for proper
installation (as shown).
Only one 1/4”-20 nut (P-B) will be used for the
recessed mounting location
P-A
P-B
P-A
P-B
• Install Screw (P-A) and Nut (P-B)
as shown.
• Tighten Screw (P-A) until snug –
DO NOT OVERTIGHTEN!
• Attach T.V. to Wing Adapters
(Part 1) using your Monitor Kit
(supplied with mount) See Step 2
for details.
• For dual nut installation, use the
second nut (P-B) as a “jam nut”.
