For application using OmniMounts VESA Compliant Monitor Plates :
P-A
P-B
P-B
• Install Screw (P-A) and
Nut (P-B) as shown.
• Tighten Screw (P-A)
until snug – DO NOT
OVERTIGHTEN!
• Attach T.V. to Wing
Adapters (Part 1) using
your Monitor Kit
(supplied with mount).
See Step 2 for details
• Install second nut (P-B)
as a “jam nut”.
NOTE:
Two 1/4”-20 nuts (P-B) must be used for proper
installation (as shown).
