EN-12 Valor 2000 Series Scales
6.3 Service Information
If the troubleshooting section does not resolve or describe your problem, contact
your authorized Ohaus service agent. For service assistance or technical support in
the United States call toll-free 1-800-526-0659 between 8.00 AM and 5:00 PM
EST. An Ohaus product service specialist will be available to provide assistance.
Outside the USA, please visit our web site,
www.ohaus.com to locate the Ohaus
office nearest you.
7. TECHNICAL DATA
The technical data is valid under the following ambient conditions:
Ambient temperature:
0°C to 40°C
Relative humidity: 10% to 95% relative humidity, non-condensing
Height above sea level: Up to 2000 m
Operability is assured at ambient temperatures between 0°C and 40°C
7.1 Specifications
TABLE 7-1. SPECIFICATIONS.
Model V21PW3 V21PW6 V21PW15
Capacity x Readability
(max x d non-approved)
3 kg x 0.0005 kg
3000 g x 0.5 g
6 lb x 0.001 lb
96 oz x 0.02 oz
6 kg x 0.001 kg
6000 g x 1 g
15 lb x 0.002 lb
240 oz x 0.05 oz
15 kg x 0.002 kg
15000 g x 2 g
30 lb x 0.005 lb
480 oz x 0.1 oz
Maximum displayed resolution 1:6000 1:6000 1:7500
Capacity x Readability
(max x e approved)
3 kg x 0.001 kg
3000 g x 1 g
6 lb x 0.002 lb
96 oz x 0.05 oz
6 kg x 0.002 kg
6000 g x 2 g
15 lb x 0.005 lb
240 oz x 0.1 oz
15 kg x 0.005 kg
15000 g x 5 g
30 lb x 0.01 lb
480 oz x 0.2 oz
Approved resolution 1:3000 1:3000 1:3000
Repeatability +0.001 kg +0.002 kg +0.005 kg
Linearity +0.001 kg +0.002 kg +0.005 kg
Weighing Units kg, g, lb, oz
Tare range To capacity by subtraction
Stabilization Time ≤ 2 seconds
Power Requirements
9-12 VDC 0.7A AC Adapter (supplied)
Internal rechargeable sealed lead-acid battery
Display
2x red LED (front and rear)
6-digit 7-segment, 15mm / 0.6 in characters
Keypad 2-button mechanical keys
Ingress Protection IP65
Pan Size (mm / in) 233 x 184 / 9.2 x 7.2
Typical Battery life 60 hours with 12 hour recharge time
Operating temperature range 0°C to 40°C
Net Weight (kg / lb) 3.5 / 7.8
Shipping Weight (kg / lb) 4.3/ 9.3
