BW SERIES COMPACT BENCH SCALE EN-5
3. OVERVIEW OF CONTROLS AND FUNCTIONS
• Turns the scale on
• Long-press turns the scale off
• Short-presses dsplay successve unts of measure
• In SETUP Mode, “Yes” accepts/confrms the dsplayed settng
• In CHECK Mode, accepts/confrms the dsplayed value
• Inputs the weght of the object on the weghng pan as a Tare value
• In SETUP Mode, “No” toggles through the avalable settngs
• In CHECK Mode, ncrements the value of the selected dgt
• Zeros the dsplay
• Wth the scale off, long-press together wth ON/UNITS OFF enters User Setup Mode
• In SETUP Mode, “Ext” ends setup and exts to “Save”
• In CHECK Mode, ends Over/Under setup and exts to weghng mode
• Intates CHECK Over/Under setup
• In SETUP Mode, “Back” reverts to the prevous parameter
• In CHECK Mode, shfts to the next dgt
• LED annuncator ndcates Center of Zero
• LED annuncator ndcates battery s fully charged (blnkng f chargng)
UNDER • LED annuncator ndcates dsplayed weght s less than the preset Under value
OVER • LED annuncator ndcates dsplayed weght s more than the preset Over value
• LED annuncator blnks to ndcate the battery voltage s low
NET • LED annuncator ndcates Net (Gross mnus Tare) value
g, oz, lb • LED annuncator ndcates the actve weghng unt
UNDER OVER NET CHECK
ZERO
9 0
TARE
Yes
Exit
Back
No
oz
g
lb
CAPACITY: 3 lb x 0.001 lb
ON/UNITS
OFF
