Explorer
®
Analytical and Precision Balances
Compliance
Metrology: NIST Handbook 44 (NTEP CC 12-012), Measurement Canada Weights and Measures Regulations
(AM-5847) (Class I, nmax 320000; Class II, nmax 42000; certified models only)
Product Safety: IEC/EN 61010-1:2010; CAN/CSA-C22.2 No. 61010-1-12; UL Std. No. 61010-1 (3rd Edition)
Electromagnetic Compatibility: IEC 61326-1; EN 61326-1:2006 (Class B); C-Tick; FCC Part 15 (Class A);
ICES-003 (Class A)
Environment: RoHS; WEEE
Accessories
Tower Mount for Display (non High Capacity models)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83021102
Tower Mount for Display** . . . . . . . . . . . . . . . . . . 30078082
Display Extension Cable (27 Feet/9 Meter) . . . 30078078
Display Extension Cable (9 Feet/3 Meter) . . . . 83021083
Density Determination Kit . . . . . . . . . . . . . . . . . . . 80253384
Draftshield Kit (0.01g, 0.1g, non High Capacity models)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83021084
Security Device (Cable & Lock) . . . . . . . . . . . . . . . . 80850000
Security Device (Laptop Lock) . . . . . . . . . . . . . . . . . 80850043
Interface Cable, USB (Type A to B) . . . . . . . . . . . . 83021085
Second RS232 Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83021081
Ethernet Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83021082
Foot Switch Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83021086
RS232 Cable & Adapter (to 80251992 Printer) 80252581
RS232 Cable, PC 25 Pin . . . . . . . . . . . . . . . . . . . . . . . 80500524
RS232 Cable, PC 9 Pin . . . . . . . . . . . . . . . . . . . . . . . . . 80500525
Impact Printer SF40A . . . . . . . . . . . . . . . . . . . . . . . . . 30064203
RS232 Cable SF40A Impact Printer . . . . . . . . . . 12122603
Compact Thermal Printer . . . . . . . . . . . . . . . . . . . . 80251992
Paper for Dot Matrix Printer (2 Rolls) . . . . . . . . 12120799
Ink Ribbon for Dot Matrix Printer . . . . . . . . . . . 12120798
Rolling Feet Kit** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30041470
External Rechargeable Battery Pack** . . . . . 30041295
Auxiliary Display PAD7 . . . . . . . . . . . . . . . . . . . . . . . 80251396
WinWedge Software . . . . . . . . . . . . . . . . . . . . . . . . . . 80850080
*Certified models only **High Capacity models only
Model EX124 EX224 EX324 EX223 EX423 EX623 EX1103 EX2202 EX4202 EX6202 EX10202 EX6201 EX10201
Automatic Door EX124/AD EX224/AD EX324/AD — — — — — — — — — —
External Calibration — — — EX223/E EX423/E — — EX2202/E EX4202/E EX6202/E — EX6201/E —
Certified Models EX124N/AD EX224N
EX224N/AD
EX324N
EX324N/AD
— EX423N — EX1103N — EX4202N — EX10202N — EX10201N
Capacity (g) 120 220 320 220 420 620 1100 2200 4200 6200 10200 6200 10200
Readability d (g) 0.0001 0.001 0.01 0.1
Verification Interval* e (g) 0.001 — 0.01 — 0.01 — 0.1 — 0.1 — 0.1
Class* I — II — I — II — I — I
Repeatability std (g) ±0.0001 ±0.001 ±0.01 ±0.1
Linearity (g) ±0.0002 ±0.002 ±0.02 ±0.2
Stabilization Time (sec) ≤2 ≤3 ≤1.5 ≤1
Sensitivity Drift (ppm/°C) 1.5 3 5 3
Typical Min-Weight
(USP, K=3, U=0.1%)
0.24g 0.24g 0.24g 2.1g 2.1g 2.1g 2.1g 21g 21g 21g 21g 210g 210g
Typical Min-Weight
(GLP K=2, U=0.1%)
0.16g 0.16g 0.16g 1.4g 1.4g 1.4g 1.4g 14g 14g 14g 14g 140g 140g
Weighing Units Gram, Milligram, Kilogram, Carat, Ounce, Ounce Troy, Pound, Pennyweight, Grain, Newton, Momme, Mesghal, Hong Kong Tael, Singapore Tael, Taiwan Tael, Tical, Tola, Baht,
Custom Unit 1, Custom Unit 2, Custom Unit 3
Weighing Units,
Certified Models mg, g, oz, lb, ct, ozt, grain, dwt —
mg, g, oz, lb,
ct, ozt, grain,
dwt
—
mg, g, oz, lb,
ct, ozt, grain,
dwt
—
g, kg, oz, lb,
ct, ozt, grain,
dwt
—
g, kg, oz, lb,
ct, ozt, grain,
dwt
—
g, kg, oz, lb,
ct, ozt, grain,
dwt
Weighing Applications Weighing, Percent Weighing, Parts Counting, Check Weighing, Dynamic/Animal Weighing, Filling, Totalization, Formulation,
Differential Weighing, Density Determination, Peak Hold, Ingredient Costing, Pipette Adjustment, SQC
Pan Size Ø 3.54 in / 90 mm Ø 5.12 in / 130 mm 7.48 × 7.87 in / 190 × 200 mm
Calibration All models feature external calibration. Models feature AutoCal™ internal calibration, except for EX.../E models
Tare Range To capacity by subtraction
Power Requirements AC Adapter Input: 100-240 VAC, 0.6A, 50-60 Hz
Display Type Full-color VGA graphic display, 4-wire resistive touch screen
Display Size 5.7 in / 145 mm (diagonal)
Display Housing (W×H×D) 7.68 Ч 3.54 Ч 6.06 in / 195 Ч 90 Ч 154 mm
Base Housing (W×H×D) 9.06 Ч 13.78 Ч 15.47 in / 230 Ч 350 Ч 393 mm 9.06 Ч 3.86 Ч 15.47 in / 230 Ч 98 Ч 393 mm
Communication RS232, USB and optional ethernet or 2 nd RS232
Temperature Range 50°F to 86°F / 10°C to 30°C
Humidity Range 80% max up to 86°F/30°C decreasing linearly to 50% at 104°F/40°C, non-condensing
Storage Conditions 140°F/60°C at 10% to 90% relative humidity, non-condensing
Net Weight 15 lbs / 6.9 kg 10 lbs / 4.3 kg 11 lbs / 5 kg
Shipping Weight 21 lbs / 9.6 kg 15 lbs / 6.8 kg 16 lbs / 7.4 kg
Shipping Dimensions 21.65 Ч 15.16 Ч 21.69 in / 55 Ч 38.5 Ч 55.1 cm 21.65 Ч 15.16 Ч 11.45 in / 55 Ч 38.5 Ч 29.1 cm
