Ingenious DRAFTSHIELD
Explorer’s draftshield provides ample access and visibility to the weighing
chamber through the versatile top door and side sliding doors. Select
models feature motorized side doors that open and close automatically
with use of the touchless sensors on the base and display.
• The automatic draftshield door models have a new function for auto-
matically opening draftshield doors without touching the balance.
It helps to eliminate sample residue transfer and contaminations.
• Side doors seamlessly glide on top-mounted
bearings
• The versatile top door offers two entry
options; access the weighing chamber by
flipping the top door or sliding the glass
panel open.
• The expansive side entry 6.3” × 9.4”
(160 mm × 240 mm) allows you to
freely place and remove large weigh boats or
other large vessels in the weighing chamber
• Antistatic coated glass helps dissipate static
charges in the weighing chamber which could adversely affect the
weighing results
• Easy to install and remove glass panels and a stainless steel bottom
make Explorer extremely easy to clean
• A draftshield chamber light is available when the balance is used in
low lighting environments
Practical TOUCHLESS SENSORS
Explorer features up to four touchless sensors for
hands-free operation of zero, print, calibration,
tare, automated draftshield doors and other
selectable functions
• Hands-free operation
—Improves weighing efficiency
—Eliminates sample residue transfer
—Minimizes contamination
• Two sensors on the base* and two on the
display can be set up individually to allow for
remote operations
• The sensors can be set up to provide automated operation of the
draftshield side doors and can be programmed to automatically open
the opposite side door in order to support efficient and logical sample
placement with your free hand.
* Analytical and precision models only.
Automatic Draftshield door operation only offered on Analytical models
