Defender
TM
5000
Low Profile Scales
80774409_F
©
Copyright
Ohaus
Corporation
OHAUS CORPORATION
* 7 Campus Drive
Suite 310
Parsippany, NJ 07054 USA
Tel: 800.672.7722
973.377.9000
Fax: 973.944.7177
www.ohaus.com
With offices throughout Europe,
Asia, and Latin America
* ISO 9001
Registered Quality Management System
Low-Profile Square Scales
Model D51P10QR5 D51P25QR5 D51P50QL5 D51P100QL5 D51P250QX5
Capacity x
Default Readability
25 lb x 0.002 lb
400 oz x 0.05 oz
25 lb : 0.05 oz
10 kg x 0.001 kg
10,000 g x 1 g
50 lb x 0.005 lb
800 oz x 0.1 oz
50 lb x 0.1 oz
25 kg x 0.002 kg
25,000 g x 2 g
100 lb x 0.01 lb
1,600 oz x 0.2 oz
160 lb : 0.2 oz
50 kg x 0.005 kg
50,000 g x 5 g
250 lb x 0.02 lb
4,000 oz x .5 oz
250 lb : .5 oz
100 kg x 0.01 kg
100,000 g x 10 g
500 lb x 0.05 lb
8,000 oz x 1 oz
500 lb : 1 oz
250 kg x 0.02 kg
250,000 g x 20 g
Maximum Displayed Resolution 1:10000 1:12500 1:10000 1:10000 1:12500
Capacity x
Certified/Approved Readability
25 lb x 0.005 lb
10 kg x 0.002 kg
50 lb x 0.01 lb
25 kg x 0.005 kg
100 lb x 0.02 lb
50 kg x 0.01 kg
250 lb x 0.05 lb
100 kg x 0.02 kg
500 lb x 0.10 lb
250 kg x 0.05 kg
Maximum Certified Resolution 1:5,000 1:5,000 1:5,000 1:5,000 1:5,000
Safe Overload Capacity 150% of maximum capacity
Scale Dimensions
(W x H1 x D1 x D2)
12 x 3.7 x 12 x 20.8 in
305 x 95 x 305 x 530 mm
18 x 4.5 x 18 x 26.8 in
457 x 115 x 457 x 680 mm
24 x 5.4 x 24 x 32.8 in
610 x 137 x 610 x 833 mm
Shipping Dimensions (L x W x H)
19.3 x 16.1 x 17.3 in
490 x 410 x 440 mm
31.2 x 23.6 x 9.5 in
810 x 600 x 240 mm
39.4 x 29.9 x 9.8 in
1000 x 760 x 250 mm
Net Weight 30.6 lb / 13.9 kg 63.7 lb / 28.9 kg 80.9 lb / 36.7 kg
Shipping Weight 35.9 lb / 16.3 kg 68.5 lb / 31.1 kg 95.0 lb / 43.1 kg
Low-Profile Rectangular Scales
Model D51P15HR5 D51P30HR5 D51P60HR5 D51P60HL5 D51P100HL5 D51P150HX5 D51P300HX5
Capacity x
Default Readability
30 lb x 0.005 lb
480 oz x 0.1 oz
30 lb : 0.1 oz
15 kg x 0.002 kg
15,000 g x 2 g
60 lb x 0.01 lb
960 oz x 0.2 oz
60 lb x 0.2 oz
30 kg x 0.005 kg
30,000 g x 5 g
150 lb x 0.02 lb
2,400 oz x 0.5 oz
160 lb : 0.5 oz
60 kg x 0.01 kg
60,000 g x 10 g
250 lb x 0.05 lb
4,000 oz x 1oz
250 lb : 1oz
100 kg x 0.02 kg
100,000 g x 20 g
300 lb x 0.05 lb
4,800 oz x 1 oz
300 lb : 1 oz
150 kg x 0.02 kg
150,000 g x 20 g
600 lb x 0.1 lb
9,600 oz x 2 oz
600 lb : 2 oz
300 kg x 0.05 kg
300,000 g x 50 g
Maximum Displayed Resolution 1:7500 1:6000 1:7500 1:5000 1:7500 1:6000
Capacity x
Certified/Approved Readability
30 lb x 0.01 lb
15 kg x 0.005 kg
60 lb x 0.02 lb
30 kg x 0.01 kg
150 lb x 0.05 lb
60 kg x 0.02 kg
250 lb x 0.1 lb
100 kg x 0.05 kg
300 lb x 0.1 lb
150 kg x 0.05 kg
600 lb x 0.2 lb
300 kg x 0.1 kg
Maximum Certified Resolution 1:3,000 1:3,000 1:3,000 1:2,500 1:3,000 1:3,000
Safe Overload Capacity 150% of maximum capacity
Scale Dimensions
(W x H1 x D1 x D2)
12 x 3.7 x 14 x 22.8 in
305 x 95 x 355 x 580 mm
15.7 x 4.1 x 19.7 x 28.5 in
400 x 105 x 500 x 725 mm
16.5 x 4.9 x 21.7 x 30.5 in
420 x 125 x 550 x 775 mm
Shipping Dimensions (L x W x H)
19.3 x 16.1 x 17.3 in
490 x 410 x 440 mm
29.1 x 27.2 x 9.1 in
740 x 690 x 230 mm
29.5 x 30 x 9.1 in
750 x 710 x 230 mm
Net Weight 23.6 lb / 10.7 kg 46.3 lb / 21.0 kg 58.2 lb / 26.4 kg
Shipping Weight 35.9 lb / 12.7 kg 53.6 lb / 24.3 kg 64.8 lb / 29.4 kg
General Specifications
Indicator Model T51P
Construction
ABS plastic indicator, stainless steel removable weighing platform, aluminum loadcell,
painted steel mounting bracket and base construction
Weighing Units lb, oz, lb:oz, kg, g, metric tonnes, custom unit
Modes Static Weighing, Dynamic Weighing, Counting, Checkweighing, Percent Weighing, Display Hold
Display 1 in / 25mm high 6-digit, 7-segment bright white backlit LCD
Keyboard 4-button membrane switch
Stabilization Time Within 2 seconds
Auto-zero Tracking Off, 0.5, 1 or 3 d
Zeroing Range 2% or 100% of capacity
Calibration Span: 1kg or 1lb to 100% of capacity / 3-point linearity (0 - 50% – 100% fixed)
Power
100-240 VAC / 50-60Hz internal universal power supply,
6 ‘C’ cell batteries (not supplied) with 80 hour life
Interface RS232 and external input
Operating Temperature Range 14°F to 104°F / -10°C to 40°C
