Defender
TM
5000
Low Profile Scales
The Defender 5000 Offers Multiple Features and Easy Configuration:
To meet different operational needs, the Defender 5000 includes a suite of configurable software:
• Counting mode for packaging and inventory control, enabling counting into a container or out of a container for bulk
operations. Supports a maximum counting resolution to 1:300,000 (minimum APW equal to 0.1d), selectable auto-optimization
of average piece weight (APW). APW data can be displayed at any time using a quick key press.
• Percent Weighing mode for formulation and mixing applications, with display of reference weight with quick key press.
• Dynamic/Animal Weighing with selectable weigh times from 0-60 seconds.
• Checkweighing function for packaging and weight checking, with display of results using LCD display and red/yellow/green
LEDs. Audible beeper can be configured to prompt when weight is within range, under, over, or under or over range.
Target weight values can be displayed at any time using a quick key press.
• Display Hold mode for weighing large packages holds last stable weight on display until cleared
• The Defender 5000 weighs in one or more user-selectable units: kg, g, lb, oz, lb:oz (decimal), metric tonnes and
user-definable custom unit
• Supports GMP/GLP data output with date, time user ID, project ID and scale ID. The Defender 5000 features selectable print
options for data and print format
• To limit operator access to functions, the Defender 5000 offers both software lockouts for menu items as well as individual
key functions.
Features
T51P Indicator: ABS plastic housing with internal rib reinforcements, reversible rear cover, backlit LCD weight display, check-
weighing indication (green, yellow, red), membrane keypad with raised tactile keys, built-in bi-directional RS232 with manual/
continuous/interval printing, external tare input, hardware configuration lockout switch, internal switching power supply with
line cord and battery power using 6 “C” cell batteries.
Other Features
Zero point calibration, calibration test, span or linear calibration, selectable auto-zero tracking range, selectable stability range,
selectable averaging level, selectable LCD backlight, selectable auto shutoff, retain zero weight data after power-off, Geo gravity
adjustment, selectable key beep, key function lock, menu lock, selectable power-on and calibration unit, battery status display,
display of gross/net weight, indication of stability, center of zero, over- and underweight, overload and underload conditions.
Configuration menus for PRINT1, PRINT2, COM1, COM2, and I/O.
Compliance
• Legal for Trade (Made from Certified/Approved weighing components): NTEP (CC No. 08-039 for indicator; 01-048A1 for square base;
99-203A3 for rectangular base)
Measurement Canada (Approval No. AM-5687 for Indicator; AM-5719 for square bases; AM-5675 for rectangular bases)
• Safety and EMC:
c
UL
us
2005/95/EC low voltage directive: EN60950-1:2001, FCC Part 15 Class A 2004/108/EC
Compliant to Directive 202/96/EC on waste electrical and electronic equipment (WEEE)
• Quality: OHAUS quality management system registered to ISO 9001:2008
Outline Dimensions
313 mm
12.4 in
260 mm
10.2 in
168 mm
6.6 in
71 mm
2.8 in
224 mm
8.8 in
H1
W
D2
D1
