7000 Series
Advanced Indicators
Other Features
Zero point calibration, calibration test, span or linear calibration, selectable auto-zero tracking range, selectable
stability range, selectable averaging level, selectable LCD backlight, selectable auto shutoff, retain zero weight data
after power-off, Geo gravity adjustment, selectable key beep, key function lock, menu lock, selectable power-on
and calibration unit, battery status display, display of gross/net weight, indication of stability, center of zero, over-
and underweight, overload and underload conditions. Configuration menus for PRINT1, PRINT2, COM1, COM2,
and I/O.
Compliance
• Legal for Trade: NTEP (COC No. 09-102) / Measurement Canada (AM-5762)
• Safety and EMC:
c
UL
us
2005/95/EC low voltage directive: EN60950-1:2001, FCC Part 15 Class A 2004/108/EC
EMC directive: EN61326-1:1997; +A1:1998; +A2:2001; + A3>2003
• Other: Compliant to Directive 2002/96/EC on waste electrical and electronic equipment (WEEE)
• Quality: OHAUS quality management system registered to ISO 9001:2008
Specifications
Indicator Models T71P T71XW
Capacity Range 1 to 999,950 kg/lb
Maximum Displayed Weighing Resolution 1:50,000
Maximum Displayed Counting Resolution 1:500,000
Certified/Approved Resolution 1:10,000
Minimum Average Piece Weight (APW) 0.1d
Weighing Units kg, lb, g, oz, lb:oz, tonnes, custom
Modes/Features
Static Weighing (single or dual range), Dynamic Weighing, Counting, Checkweighing,
Percent Weighing, Display Hold, Accumulation, Library
Housing ABS plastic with reversible rear cover 304 stainless steel enclosure, NEMA 4X / IP66
Display 6-digit, 7-segment LCD, 25mm/1 inch high primary digits, dual line, with high-contrast white LED backlight
Checkweigh Indication 3-color checkweigh LED with configurable beeper signal
Keypad Positive feedback membrane keys, 5 function keys and alpha-numeric keypad
Load Cell Excitation Voltage 5V DC
Load Cell Drive Up to 8 x 350 ohm load cells
Load Cell Input Sensitivity Up to 3 mV/V
Stabilization Time Within 2 seconds
Auto-Zero Tracking Off, O.5, 1 or 3d
Zeroing Range 2% or 100% of capacity
Calibration Span: 1kg or 1lb to 100% of capacity / Linearity: 3 or 5 point
Interface
Built-in RS232 and External Tare Input included
Optional 2nd RS232, RS422/485, AC Relay or DC relay available
Overall Dimensions (inc. bracket) (W x D x H) 10.2 x 2.7 x 8.8 in / 260 x 71 x 224 mm 10.3 x 3 x 8.7 in / 262 x 76 x 212 mm
Enclosure Dimensions (W x D x H) 10.2 x 2.7 x 6.6 in / 260 x 71 x 168 mm 10.3 x 3 x 5.8 in / 262 x 76 x 149 mm
Net Weight 3.3 lb / 1.5 kg 7.7 lb / 3.5 kg
Shipping Weight 5.0 lb / 2.3 kg 9.5 lb / 4.3 kg
Shipping Dimensions (W x D x H) 13 x 9.5 x 7 in / 330 x 240 x 180 mm
Operating Temperature Range 14°F to 104°F / -10°C to 40°C
Relative Humidity Range Maximum 80% up to 88°F/31°C, decreasing linearly to 50% at 104°F/40°C
Power
100-240 VAC / 50-60 Hz
Internal universal power supply, line cord
6 ‘C’ cell batteries (not supplied) with 80 hour life
Opt. Int. rechargeable NiMH battery (10-hr. typical operation)
100-240 VAC / 50-60 Hz
Internal universal power supply, hardwire cord
Opt. Int. rechargeable NiMH battery (10-hr. typical operation)
80774470_B
©
Copyright
Ohaus
Corporation
OHAUS CORPORATION
* 7 Campus Drive
Suite 310
Parsippany, NJ 07054 USA
Tel: 800.672.7722
973.377.9000
Fax: 973.944.7177
www.ohaus.com
With offices throughout Europe,
Asia, and Latin America
* ISO 9001
Registered Quality Management System
Outline Dimensions
313 mm
12.4 in
260 mm
10.2 in
168 mm
6.6 in
71 mm
2.8 in
224 mm
8.8 in
315 mm
12.4 in
262 mm
10.3 in
149 mm
5.86 in
76 mm
3.0 in
212 mm
8.3 in
T71XW Indicator T71P Indicator
