Ohaus DEFENDER 7000 WEIGHING INDICATOR Data Sheet - Manual (Page 2)

7000 Series
Advanced Indicators
7000 Series Indicators Offer Multiple Features and Easy Configuration:
To meet different operational needs, the 7000 Series includes a suite of configurable software:
• Counting mode for packaging and inventory control, enabling counting into a container or out of a container for bulk
operations. Supports a maximum counting resolution to 1:500,000 (minimum APW equal to 0.1d), selectable auto-
optimization of average piece weight (APW). APW data can be displayed at any time using a quick key press.
• Percent Weighing mode for formulation and mixing applications, with display of reference weight with quick key press.
• Dynamic/Animal Weighing with selectable averaging times from 0-60 seconds.
• Checkweighing function for count and weight checking, with display of results using LCD display and red/yellow/green
LEDs. Audible beeper can be configured to prompt when weight is within range, under, over, or under or over range.
Target values can be displayed at any time using a quick key press.
• Display Hold mode for weighing large packages, holds last stable weight on display until cleared manually or automatically
• Weighs in one or more user-selectable units: kg, g, lb, oz, lb:oz (decimal), tonnes and user-definable custom unit
• Supports GMP/GLP data output with date, time user ID, project ID and scale ID. The Defender 7000 features selectable
print options for data and print format
• Software lockouts for menu items as well as individual key functions to limit operator access to functions.
• Library storage for up to 255 memory records that may contain data from a combination of different modes. These refer-
ence data can be quickly and conveniently recalled for use with the active mode.
• Multi-language feature allows the user to display operation and menu text in the language of their choice: English, Spanish,
French, German, Italian. This allows for convenience and ease of training and operation of the Defender 7000.
• Accumulation mode with statistics feature allows totalizing weight and count values manually or automatically. The total
accumulated value is displayed in real-time. With the press of the “Info” key, the number of weighments, average, standard
deviation, minimum, maximum and difference are displayed. These statistical values can also be printed.
• Dual scale connections are built-in for 2-scale counting configuration. Connect two bases, a higher resolution base to opti-
mize average piece weight, in conjunction with a large capacity base to weigh/count in bulk.
• Store, view and print over 262,000 date and time-stamped weighing results with the optional Alibi memory kit.
Options and Accessories
Interface Options
OHAUS Number
AC Relay Kit, T71P/T71XW .....................................................80500720
DC Relay Kit, T71P/T71XW .....................................................80500727
RS485/422 Interface Kit, T71P/T71XW ...................................80500731
RS232 Interface Kit, T71P/T71XW ..........................................80500733
Foot Switch .............................................................................71173378
Power Options
Rechargeable Battery Kit, T71P/T71XW ..................................80500729
Mounting Accessories
Wall Mount Kit, T71P ..............................................................72200227
Wall Mount Kit, T71XW ..........................................................80500735
Base Mount Kit, T71P .............................................................80500722
Column Mount Kit, 35cm, painted, T71 ..................................80500723
Column Mount Kit, 68cm, painted, T71 ..................................80500724
Column Mount Kit, 35cm, stainless steel, T71 .......................80500725
Column Mount Kit, 68cm, stainless steel, T71 .......................80500726
Compatible with all existing columns for Champs-CD/CW11/CD3X/CKW
Other Accessories OHAUS Number
Compact Dot Matrix Impact Printer ........................................80252042
Compact Thermal Printer ........................................................80251992
OHAUS Collect Software .........................................................80500746
Alibi Memory Option Kit ..........................................................80500503
TAL Software WinWedge ........................................................SW12W
Paper for Printer, 80252042 (1 roll) .......................................80251932
Ribbon for Printer, 80252042 .................................................80251933
RS232 Cable & Adapter, 80252042 Printer to T71XW ...........80252574
RS232 Cable, PC 9 Pin to T71XW ..........................................80500552
RS232 Cable, PC 25-pin to T71XW ........................................80500553
RS232 Cable & Adapter, 80252042 Printer to T71P ...............80252571
RS232 Cable, PC 9-pin to T71 ................................................80500525
RS232 Cable, PC 25-pin to T71P ............................................80500524
