VN Series
Economical Floor Scales and Platforms
Specifications
Scale Models
VN31P5000L
VN31P5000X
NTEP Certified Capacity x Readability
5000 lb x 1 lb /
2500 kg x 0.5 kg
NTEP Resolution
1:5,000
Indicator
T31P
Construction
5mm / 0.196 in painted carbon steel platform with ABS housed indicator
Load Cell
4 x 2,500 lb nickel-plated alloy steel shear beam IP67 protected
Feet
4 x self-swiveling ball-in-cup design with rubber bottom, adjustable height top levelling
Junction Box
NEMA 4X / IP65, 304 stainless steel, with 16.5 ft / 3 m long indicator cable
Maximum Central Load
160% of maximum capacity
Safe Endload Capacity
100% of maximum capacity
Protection
IP67 for shear beam load cells, NEMA4X/IP65 for junction box
Weighing Units
lb or kg
Modes
Weighing, Counting*
Display
1 in / 25 mm high, 6-digit, 7-segment bright white backlit LCD
Keyboard
4-button mechanical switches
Stabilization Time
Within 2 seconds
Auto-zero Tracking
Off, 0.5, 1 or 3d
Zeroing Range
0%, 2% or 100% of capacity
Span Calibration
5 lb or kg to 100% of capacity
Interface
RS232C, bidirectional
Operating Temperature Range
14°F to 104°F / -10°C to 40°C
Power
9VDC, 0.5A AC adapter or internal rechargeable sealed lead acid battery
(100-hour typical operation with full charge) – both included
Platform Dimensions (W x D x H)
4ft x 4ft x 3.5 in
5ft x 5ft x 3.5 in
Indicator Dimensions (W x D x H)
8.2 x 2.8 x 6.5 in / 210 x 71 x 168 mm
Scale Shipping Dimensions (W x D x H)
64.6 x 53 x 13.4 in / 1640 x 1350 x 340 mm
75.4 x 64 x 13.4 in / 1915 x 1626 x 340 mm
Net Weight
282 lb / 128 kg
419 lb / 190 kg
Shipping Weight
333 lb / 151 kg
533 lb / 242 kg
* Counting feature not NTEP certified
Platform Models
VN5000L
VN5000X
NTEP Certified Capacity x Readability
5000 lb x 1 lb
2500 kg x 0.5 kg
NTEP Resolution
1:5,000
Platform Construction
5mm / 0.2 in painted carbon steel platform
Load Cell
4 x 2,500 lb nickel-plated alloy steel shear beam IP67 protected
Feet
4 x self-swiveling ball-in-cup design with rubber bottom, adjustable height
Junction Box
NEMA4X/IP65, 304 stainless steel, with 16.5 ft / 3 m long indicator cable
Maximum Central Load
160% of maximum capacity
Safe Endload Capacity
100% of maximum capacity
LC Output Impedance / Excitation Voltage
350 ohm / 10V DC ~max 15V
Protection
IP67 for shear beam load cells, IP65/NEMA4X for junction box
Operating Temperature
14°F to 104°F / -10°C to 40°C
Platform Dimensions
4 ft x 4 ft x 3.5 in
5 ft x 5 ft x 3.5 in
Shipping Dimensions
48.4 x 48.4 x 10.6 in / 1230 x 1230 x 270 mm
60.4 x 60.4 x 10.6 in / 1535 x 1535 x 270 mm
Net Weight
271 lb / 123 kg
408 lb / 185 kg
Shipping Weight
289 lb / 131 kg
430 lb / 195 kg
Compliance
• Safety and EMC: EN60950, EN61326, FCC, CE,
C
UL
US
• NTEP Certifications: T31P Indicator: CC 08-066, Load Cell: CC 91-043A4, VN Platform: CC 08-048A1
• Quality: OHAUS quality management system registered to ISO 9001:2000
