VN Series
Economical Floor Scales and Platforms
VN Series Floor Scales Include The Durable T31P Indicator
T31P Features:
• Large 1” high digit backlit LCD display quickly displays results
in a choice of lb or kg. The power-on unit is selectable, and
either the lb or kg unit can be turned off for easier use.
• Includes Counting Mode with a minimum Average Piece
Weight of 1d, selectable sample sizes, automatic retention
of last sample size used and Average Piece Weight. For
installations where Counting Mode is not required, the
parts counting software can be selected off.
• Built-in bidirectional RS232C interface for printing or
connection to PC. Printing intervals can be set to manual
(using Print key), continuous, on stable weight, or an
interval between 1 second and 60 minutes.
• Geographical gravity correction software allows quick
adjustment of calibration to local conditions without need
for recalibration of the VN Floor Scale. All VN Floor Scales
are factory calibrated and must be set to match local gravity
situation.
• Durable mechanical switch keypad with dedicated Print, Tare and Function keys
for quick and easy operation
• Powered using either the included AC adapter or the included 100-hour internal rechargeable battery pack.
• Reversible back which allows installation with the floor platform and power connections exiting from the top or the bottom of
the indicator housing.
• The T31P includes four wall mounting holes for screw mounting to bench or wall – it can also be wall or table mounted using
the included wall mount bracket for full tilt adjustment of the indicator.
• Software lockouts of menu operations for setup, readout, mode, unit and print menu options. In NTEP certified operation,
certain menu options are automatically locked-out.
Options
• Ramps
4’ or 5’ wide
with foot mounting
plates
• Fixed Location
Foot Mounting Plate Kits
Set of 2
Indicator Accessories
Description OHAUS Number
Compact Dot Matrix Impact Printer .................... 80252042
Compact Thermal Printer .................................... 80251992
Ohaus Collect Software ....................................... 80500746
TAL Software WinWedge .................................... SW12W
Paper for Printer, 80252042 (1 roll) ................... 80251932
Ribbon for Printer, 80252042 ............................. 80251933
RS232 Cable & Adapter, 80252042
Printer to T31P ................................................... 80252571
RS232 Cable, PC 9-pin to T31P .......................... 80500525
RS232 Cable, PC 25-pin to T31P ........................ 80500524
