AUX-IN OPERATION
This unit has provided special AUX-IN jack, through this jack other audio sources can be
connected to this unit and be amplified.
1. Set the FUNCTION switch to CD/MP3/USB/AUX position.
2. Connect the audio cable into the AUX-IN jack and the other end connect to the AUDIO OUT
jack of the external audio source. The unit will change to AUX mode automatically.
3. Adjust the volume of the main unit to your desired level.Press PLAY of the external audio
source (eg. MP3 player) to start playback.
SPECIFICATIONS
GENERAL
Power Requirement AC 110/220V ~ 60/50Hz
DC 12V 8 x 1.5V UM-1 / D size
Power Consumption
AC 18 Watts
Weight Approx. 2.2 kg
Dimensions Approx.385mm (W) x 240 mm (D) x 155mm (H)
Operation Temperature +5°C - +35° C
CD SECTION
Channels: 2 channels
Optical pick-up: 3 beams laser
Frequency Response: 100Hz - 16KHz
RADIO SECTION
Receiving Band: AM/FM
Tuning Range: AM: 530 - 1710 KHz
FM: 88 - 108 MHz
Antenna: FM rod antenna, AM built-in ferrite bar
AUDIO SECTION
Power Output 1.8 Watts x 2
ACCESSORIES
Instruction Booklet 1
AC Cord 1
ESD Remark:
In case of malfunction due to electrostatic discharge, just reset the product (reconnect of power
source may be required) to resume normal operation.
