Herman Miller Caper Multipurpose Chair - Disassembly For Recycling User Manual
Page 2
Z
© 2012 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Z, Caper are among the registered trademarks of Herman Miller, Inc.
TM
Sense, Setu, and Tu are among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b9rtf rev A.
2
4. Lift the base from
pneumatic cylinder and pull
off.
5. Remove cylinder from tilt
by hitting bottom of tilt with
mallet.
6. Pull out the cylinder from
assembly.
3. Using a 7/8” dia socket, or
something equivalent, strike
socket to dislodge the base
from the cylinder.
