Please Note: Our suggested box volumes are given as internal air requirements
Recommended Enclosures
Installation Instructions / Owner’s Manual
DB Research L.L.P.
302 Hanmore Industrial Parkway // Harlingen, TX 78550
ph: 877.787.0101 // fx: 956.421.4513 // www.dbdrive.net ®
MODEL
K9 10D4
K9 12D2 / K9 12D4
K9 15D2 / K9 15D4
Sealed Enclosure
Box Volume 1.20cu ft.
Ported Enclosure
Box Volume 1.43cu ft.
Box Tuning 38Hz
Port Diameter 4in
Port Length 16in
K9 10D4
Sealed Enclosure
Box Volume 1.36cu ft.
Ported Enclosure
Box Volume 1.90cu ft.
Box Tuning 38Hz
Port Diameter 2 x 4in
Port Length 24in
K9 12D2 / K9 12D4
Sealed Enclosure
Box Volume 1.77cu ft.
Ported Enclosure
Box Volume 2.66cu ft.
Box Tuning 38Hz
Port Diameter 2 x 4in
Port Length 19in
K9 15D2 / K9 15D4
sealed ported
159mm/6.25in
234mm/9.21in
259.5mm/10.21 in
169mm/6.65in
284mm/11.18in
312.5mm/12.30in
196.5mm/7.74in
358mm/14.09in
388.5mm/15.3in
