Please Note: Our suggested box volumes are given as internal air requirements
Recommended Enclosures
Installation Instructions / Owner’s Manual
DB Research L.L.P.
302 Hanmore Industrial Parkway // Harlingen, TX 78550
ph: 877.787.0101 // fx: 956.421.4513 // www.dbdrive.net ®
MODEL
K2 10D4 / K2 12D4 / K2 12D2
Sealed Enclosure
Box Volume .74 cu ft.
Ported Enclosure
Box Volume 1.14 cu ft.
Box Tuning 39hz
Port Diameter 3in.
Port Length 9in.
K2 10D4
sealed ported
Sealed Enclosure
Box Volume 1.15 cu ft.
Ported Enclosure
Box Volume 1.65 cu ft.
Box Tuning 39hz
Port Diameter 4in.
Port Length 11in.
K2 12D4
Sealed Enclosure
Box Volume 1.15 cu ft.
Ported Enclosure
Box Volume 1.65 cu ft.
Box Tuning 39hz
Port Diameter 4in.
Port Length 11in.
K2 12D2
131mm/5.16in
257mm/10.12in
231mm/9.1in
142.3mm/5.6in
310mm/12.2in
277mm/10.91in
142.3mm/5.6in
310mm/12.2in
277mm/10.91in
