1. Slide the tab on the left side of the drive-panel insert under the center drive panel tab.
2. Rotate the drive-panel insert into place and snap the drive-panel insert tab over the corresponding tab on the drive panel.
3. Ensure that the drive-panel insert is correctly seated in the drive panel.
Installing the Drive Panel
1. Follow the procedures in Before You Begin .
2. Align the drive panel tabs with the side-door hinges.
3. Rotate the drive panel toward the computer until the sliding plate lever clicks into place and the drive panel snaps into place on the front panel.
Drives
Your computer supports:
l Two hard drives (Serial ATA)
l Two CD or DVD drives
l Two FlexBay drives (can contain an optional floppy drive and optional Media Card Reader)
1 center drive-panel tab 2 drive panel 3 drive-panel insert tab
4 drive-panel insert
1 sliding plate 2 sliding plate lever 3 drive panel
