Anschlussschema, Anschluss der einheit – Pioneer ND-G500 User Manual
Page 16
Anschluss der Einheit
3
Anschlussschema
AMP-Steuerung
Dieses Produkt
Blau/weiß
GS 5 V
Audioausgang (Links/Rechts)
Schwarz
Schwarz
Schwarz
Zum Navigationssystem
(TO NAVI)
Audioeingang
(AUDIO IN)
Rückansicht (AVIC-F500BT)
Träger (mit dem AVIC-F500BT
mitgeliefert)
Mit dem AVIC-F500BT mitgeliefert
Stecker
Buchse
Zum Auto
(TO CAR)
