Diagrama de conexión, Conexión de la unidad – Pioneer ND-G500 User Manual
Page 10
Conexión de la unidad
3
Diagrama de conexión
Azul/blanco
Control AMP
Salida de audio (Izquierda/Derecha)
Negro
Negro
Negro
DC 5V
Este producto
Al sistema de navegación
(TO NAVI)
Entrada de audio
(AUDIO IN)
Vista trasera (AVIC-F500BT)
Base (Suministrada con
AVIC-F500BT)
Suministrada con AVIC-F500BT
Macho
Hembra
Al vehículo
(TO CAR)
