English - 2
The product is intended for the cutting of grass and
weeds under bushes, as well as on slopes and
edges that can not be reached with the lawn mower.
Intended Use is related to operation within 0 °C and
40 °C ambient temperature.
This manual gives instructions on the correct as-
sembly and safe use of your machine. It is important
that you read these instructions carefully.
Carefully remove the machine from its packaging
and check that you have all the following items:
– Trimmer (in two halves)
– Cutting guard
– Operating instructions
When parts are missing or damaged, please contact your
dealer.
1 On/Off switch
2 Handle
3 Guide handle
4 Shaft, upper
5 Shaft, lower
6 Trimmer head
7 Ventilation slots
8 Cutting guard
9 Mains plug**
10 Cable hook
11 Serial Number
**Country specific
Not all of the accessories illustrated or described are
included as standard delivery.
Electrical Safety
Your machine is double insulated for safety and re-
quires no earth connection. The operating voltage is
230
V AC, 50 Hz (for non-EU countries 220 V,
240 V as applicable). Only use approved extension
cables. Contact your Bosch Service Center for de-
tails.
It is recommended for increased electrical safety to
use a Residual Current Device (RCD) with a tripping
current of not more than 30 mA. Always check your
RCD every time you use it.
WARNING: For safety, it is essential that the
mains plug 9 attached to the machine is fitted to the
power supply cable 12.
The couplings of connection leads must be pro-
tected against splashes and the coupling sockets on
the leads must be made of rubber or coated with rub-
ber.
Fixing means for the connection leads must be used.
The connection lead must be inspected for signs of
damage at regular intervals and may only be used if
in perfect condition.
Technical data
Line trimmer ART 23 EASYTRIM/
ART 2300 EASYTRIM ART 26 EASYTRIM/
ART 2600 EASYTRIM
Part number (typ) 3 600 H78 A.. 3 600 H78 G..
Rated power [W] 280 300
No-load speed [min
-1
] 12 500 11 900
Cutting line feed Pro tap automatic Pro tap automatic
Cutting line [mm] Ш 1.6 Ш 1.6
Cutting spool capacity [m] 8 8
Cutting circle [cm] 23 26
Weight (without optional extras) [kg] 1.6 1.7
Protection class / II / II
Serial Number See serial No 11 (rating plate) on machine.
Intended Use
Introduction
Delivered Items
Operating Controls
For Your Safety
Warning! Switch off, remove plug from mains
before adjusting, cleaning or if cable is cut,
damaged or entangled.
The cutting line continues to rotate for a few
seconds after the trimmer is switched off.
Caution – do not touch rotating cutting line.
C
